Laser cleaning equipment is a new generation of surface cleaning high-tech products. Laser cleaning has the characteristics of non grinding and non-contact. It can be used not only to remove organic pollutants, but also to remove inorganic substances. It is very easy to install, manipulate and achieve automate.
High efficiency and environmental protection, no chemical pollution, easy operation, you only turn on the power and open the device, machine will be cleaned with no chemical reagents, no media, no dust and no water. No disassembly and transportation of molds, no damage to the substrate surface, no consumables when powered on, adjustable laser parameters, fit curved surface cleaning, good surface cleanliness. Laser cleaning machine can clean the resin of subject surface, oil stains, stains, dirt, rust, coating, coating, paint, etc.
Comparison of Different Cleaning Methods
Comparison item
Laser cleaning
Chemical cleaning
Mechanical cleaning
Dry ice cleaning
Ultrasonic cleaning
Cleaning Method
Laser,non-contact cleaning
Chemical cleaning agent contact type
Mechanical/sandpaper contact type
Dry ice,non-contact
Cleaning agent contact type
Workpiece Damage
Slight
Damaged
Damaged
No Damage
No Damage
Cleaning Efficiency
High
Low
Low
Medium
Medium
Cleaning effect
Very good high cleanliness
Generally,uneven
Generally,uneven
Excellent,uneven
Excellent small cleaning area
Safety/Environmental Protection
No pollution
Polluted environment
Polluted environment
No pollution
No pollution
Consumables
Only electricity
Chemical cleaning agent
Sandpaper,griding wheel whetstone,etc.
Dry ice
Dedicated cleaning fluid
Operation
Easy to operate handheld or automated
Complicated process high requirements need pollution protection
Manual operation need pollution protection
Easy to operate handheld or automated
Easy to operate but need to add consumables manually
Cost investment
High initial investment,no consumables,low maintenance cost
Low initial investment,high cost of consumables
High initial investment,low labor cost for consumables
Medium investment,high cost of consumables
Low initial investment,medium cost of consumables
Specification
Model
IFCL-100
IFCL-200
IFCL-500
Laser Power
100W
200W
500W
Laser Wavelength
1064±5nm
Optional
Hand/automatic
Scanning width
10-100mm
Working temperature
0-60°C
Pulse width（ns）
130-160
Power adjustment range（%）
10-100(Gradient adjustable)
Consumption
1000W
2500W
4000W
Feature
1. Perfect appearance design, convenient to carry and transport.
2. The body is small and exquisite and does not occupy any space.
3. Using MOPA laser, powerful and stable performance.
4. The laser head is small, light and easy to move
5. The wireless remote control function is safe and practical.
Application
rust removal, paint removal, oil removal, cultural relic restoration, glue removal, coating removal etc.
